NIL Technologies Reports 94% Efficiency in Meta-Optical Lens

Facebook X LinkedIn Email
COPENHAGEN, Denmark, Oct. 13, 2021 — Optical solutions company NIL Technology (NILT) reports that is has designed, built, and characterized multiple meta-optical element (MOE) lenses with 94% absolute efficiency. The demonstration was done with 940-nm NIR lens, with results being heralded as a major milestone for the commercial use of metalenses. NILT said in a press release that the metalenses are the first flat lenses that can compete with refractive optics. Surface of a meta-optical element developed by NIL Technologies. The company said the lenses are ready to be delivered and mass produced. Courtesy of NIL Technologies....Read full article

Related content from Photonics Media



    Articles


    Products


    Photonics Handbook Articles


    White Papers


    Webinars


    Photonics Dictionary Terms


    Media


    Photonics Buyers' Guide Categories


    Companies
    Published: October 2021
    Glossary
    metalens
    A metalens, short for "metasurface lens," is a type of optical lens that uses nanostructured materials to manipulate light at a subwavelength scale. Unlike traditional lenses made of glass or other transparent materials, metalenses do not rely on the curvature of their surface to refract or focus light. Instead, they use carefully engineered patterns of nanostructures, such as nanoscale antennas or dielectric structures, to control the phase and amplitude of light across the lens's surface....
    near-infrared
    The shortest wavelengths of the infrared region, nominally 0.75 to 3 µm.
    nanoimprint lithography
    Nanoimprint lithography (NIL) is a nanolithography technique used for fabricating nanoscale patterns on a substrate. It is a high-resolution, high-throughput process that involves the mechanical deformation of a resist material on a substrate to create the desired nanostructures. The process is similar to traditional embossing, where a mold or template is pressed into a material to replicate a pattern. Here are the key elements and steps involved in nanoimprint lithography: Template/mold...
    lithography
    Lithography is a key process used in microfabrication and semiconductor manufacturing to create intricate patterns on the surface of substrates, typically silicon wafers. It involves the transfer of a desired pattern onto a photosensitive material called a resist, which is coated onto the substrate. The resist is then selectively exposed to light or other radiation using a mask or reticle that contains the pattern of interest. The lithography process can be broadly categorized into several...
    efficiency
    As applied to a device or machine, the ratio of total power input to the usable power output of the device.
