SM-CFTX Fiber Optic Coupler


This compact fiber translator uses our vibration-resistant OTX.5 series multi-axis optic positioners, which can take a 3G jolt without moving, as the basis for the design. 100 TPI hex adjustment screws provide an accurate sub-micron translation. The Y-axis knob uses a unique capture screw design to ensure no drift due to overloading in that axis. For added stability after alignment, we have added non-influencing axis locks to maintain stability in challenging environments.

Product Features:
100 pitch adjustment screws
Compatible with CFC series chucks
Aspheric coupling lens for diffraction-limited performance
Axis locks
Non-rotating focus adjustment
Crossed roller construction

Performance Specifications:
Travel
X and Y axes: 0.125 inch (3 mm)
Z axis: 0.250 inch (6 mm)

Minimum controllable motion*
X, Y, and Z axes: submicron
*Minimum controllable motion*: BASED ON 1° OF ADJUSTMENT SCREW ROTATION
SM-CFTX Fiber Optic Coupler

Siskiyou Corporation
110 SW Booth St.
Grants Pass, OR 97526
United States
Phone: +1 541-479-8697
Fax: +1 541-479-3314
Toll-free: +1 877-313-6418
