- Company: Moore Nanotechnology Systems LLC
- Type: Diamond Turning
- Optics Compatibility: Spherical, Aspherical, Cylindrical, Prisms & Wedges, Freeform
- Diameter / Dimension: 0mm - 310mm
- Width: 1.3m
- Height: 1.6m
- Length: 1.5m
- Volts: 230
- Amps: 35
- Programming Resolution: 0.01 nm
- Feedback Resolution: 8 pm
- Porous Graphite Air Bearing Spindle: 10,000 rpm
- X, Z Slide Travels: 200 mm
Functional Performance
- High Purity Aluminum Alloy
- 75 mm dia, 250 mm radius convex
- Form Accuracy (P-V): ≤0.1 µm / 75 mm
- Surface Finish (Ra): ≤2 nm
