Cerium doped Yttrium Aluminum Garnet

  • Company: Luxium Solutions
  • Type: UV
  • Light Spectrum: UV
  • Density (gms/cm3): 4.55
  • Hardness (Mho): 8.5
  • Refractive Index: 1.82
  • Emission Wavelength (nm): 550
  • Decay Time (ns): 70
  • Light Output Photon/keV: 8

YAG(Ce) is a non-hygroscopic, chemically inert inorganic scintillator with high electron conversion efficiency.
Its light yield increases linearly with the total energy of the electron beam, whereas the response of phosphors dramatically decreases. The mechanical ruggedness and good thermal conductivity provide hardness to electron beams, thus a long lifetime is expected.
Vacuum compatibility.
Cerium doped Yttrium Aluminum Garnet

Luxium Solutions
33 Powers St.
Milford, NH 03055
United States
Phone: +1 603-673-5831
Fax: +1 603-673-1256
Toll-free: +1 800-899-5831
