- Company: Imperx Inc.
- Type: CMOS
- Max. Resolution: 25MP
- Scan Type & Rate: Area Scan
- Frames (fps) at Max. Res.: 80
- Interface: CoaXPress
- Color/Mono.: Both
- Spectral Range: NIR
- Applications: Biomedical/Medical, Communications, Industrial, Information Processing, Military, Scientific Research, Other
- Pixel Size: 4.5 µm
- Shutter Type: Global Shutter (GS)
- Sensor: ON Semi NOIP1xx025KA
- Military Standard: MIL-STD-810G
- Max. Resolution: 5120 (H) × 5120 (V)
- Dynamic Range: 59 dB
Sensor: Python NOIP1xx025KA, CMOS color/mono/ENIR
Sensor Format: 23 mm (H) × 23 mm (V) 32.5 mm diagonal, APS-H optical format
Environmental: -40 °C to +70 °C Operating, -50 °C to +90 °CStorage
Humidity: 10% to 90% non-condensing
MTBF: >323,000 hours @ 40 °C (Telcordia SR-332)
Data Corrections: Bad Pixel Correction (static), flat field
correction, fixed pattern noise
